Centaflex 16AS Original

Centaflex 16AS type 0-S Original

Dimensions:
A: 42
d3: 150
E: 36
G: 18
HD: 70
P1: 25.2
R2: 12.2
S: 6
T2: 18.3
Ts: 19.1

Technical Specifications:
Rubber Quality [Shore A]: 60
Nominal torque [TKN] kNm: 0.200
Maximum torque [TKmax] kNm: 0.560
Continuous vibratory torque [TKW] kNm: 0.080
Permissible power loss [PKV] W: 40
Dynamic torsional stiffness [CTdyn] kNm/rad: 3.40

Sold as is – Only the rubber Element – No bolts – No hub

All rubber elements are also available in NR 50 Shore, 60 Shore, or Silicone.

JPN PAT.778322
US PAT.3683643
DBP 2019608
