Centaflex 2A Original

Centaflex 2A type 0 Original

Dimensions:
A: 24
d3: 85
E: 20
G: 10
HD: 40
P1: 12
P2: 14.2
M: 8

Technical Specifications:
Rubber Quality [Shore A]: 60
Nominal torque [TKN] kNm: 0.020
Maximum torque [TKmax] kNm: 0.060
Continuous vibratory torque [TKW] kNm: 0.010
Permissible power loss [PKV] W: 10
Dynamic torsional stiffness [CTdyn] kNm/rad: 0.29

Sold as is – Only the rubber Element – No bolts – No hub

All rubber elements are also available in NR 50 Shore, 60 Shore, or Silicone.

Original Spares marked with one or more of the following patents:
JPN PAT.778322
US PAT.3683643
DBP 2019608
