Centaflex 8AS Original

Centaflex 8AS type 0-S Original

Dimensions:
A: 32
d3: 120
E: 28
G: 14
HD: 60
P1: 20.5
R2: 10.2
S: 4
T2: 16.5
Ts: 17.1

Technical Specifications:
Rubber Quality [Shore A]: 60
Nominal torque [TKN] kNm: 0.100
Maximum torque [TKmax] kNm: 0.280
Continuous vibratory torque [TKW] kNm: 0.040
Permissible power loss [PKV] W: 25
Dynamic torsional stiffness [CTdyn] kNm/rad: 1.50

Sold as is – Only the rubber Element – No bolts – No hub

All rubber elements are also available in NR 50 Shore, 60 Shore, or Silicone.

JPN PAT.778322
US PAT.3683643
DBP 2019608
