Centaflex DS size 22 (021-60439-000)

Centaflex DS size 22 Complete coupling CF-DS-22

External Diameter: 336
Hub (Z): 26
Hub d: 31.8
Hub D2: 34.8
Holes: Ø11×6

Centa marine damper plate (drive plate, Centaflex dual stage coupling) for marine use.

CENTA: 021-60439-000 | 021 60439000 | 021D-00022-0335 | CI-000192
Twin Disc: IT4648054

Used on:
Twin Disc / Technodrive: TM 170 / TM 485 A1 / MG 5020 / MG 5025
ZF: ZF 45 / ZF 63 / ZF 63 A
Yanmar: 4JH2

This Centa marine damper plate, also known as a drive plate or Centaflex dual-stage coupling is specifically developed for marine use. Its dual-stage elastic design effectively absorbs torsional vibrations and shock loads, protecting gearboxes and drivetrains while enhancing operational comfort and efficiency.
