Centaflex DS size 22 (A-3210636/A)

Centaflex DS size 22 Complete coupling CF-DS-22

External Diameter: 275
PCD: 250
Hub (Z): 26
Hub d: 31.8
Hub D2: 34.8
Holes: Ø9 x6

Centa marine damper plate (drive plate, Centaflex dual stage coupling) for marine use.

CENTA: A-3-21-0636 / A-3210636/A / (PN 021-0672-00 refers solely to the hub)

This Centa marine damper plate, also known as a drive plate or Centaflex dual-stage coupling is specifically developed for marine use. Its dual-stage elastic design effectively absorbs torsional vibrations and shock loads, protecting gearboxes and drivetrains while enhancing operational comfort and efficiency.
