Centaflex DS size 30 (021-65601-000)

Centaflex DS size 30 SAE 11.5 Ø352,42mm – SAE 11,5 – 26 Teeth

External Diameter: 352.3
SAE: 11.5
PCD: 334
Hub (Z): 26
Hub d: 31.8
Hub D2: 34.8
Holes: Ø11×8

Centa marine damper plate (drive plate, Centaflex dual stage coupling) for marine use.

CENTA: 021-65601-000 | 65601 000 | 021-60513-000 | 021D-00030-0011 | CF-DS-30-011-60513 | CF-DS-30-011-0513 | CF-DS-30-011-65601 | 021-65601-000 | 021D-00030-0011 | CI-000020
TMC: 4648021 | 4648020
Twin Disc: IT4648020
ZF: 3313316004

Used on:
Twin Disc / Technodrive: TM 170 / TM 880 A
ZF: ZF 220 / ZF 220 A / ZF 80 / IRM220A / IRM220
YANMAR: 6LY UTE, Cummins 6BTA, QSB 5.9

This Centa marine damper plate, also known as a drive plate or Centaflex dual-stage coupling is specifically developed for marine use. Its dual-stage elastic design effectively absorbs torsional vibrations and shock loads, protecting gearboxes and drivetrains while enhancing operational comfort and efficiency.
