Centaflex DS size 30 (021-60513-001)

Centaflex DS size 30 SAE 11.5- 26 Teeth | CF-DS-30-011-60513

External Diameter: 352.3
SAE: 11.5
PCD: 334
Hub (Z): 26
Hub d: 31.8
Hub D2: 34.8
Holes: Ø11×8

Centa marine damper plate (drive plate, Centaflex dual stage coupling) for marine use.

CENTA: 021-60513-001 | 60513001 | 02160513001 | CI-000168
ZF: 3313316003
Twin Disc: IT4648021

Used on
ZF: ZF 63 / ZF 63A / ZF 63 IV /  ZF 220 / ZF 220 A / ZF 85
Twin Disc / Technodrive: TM 880 A / MG 5055 A
Yanmar: 6LYUTE
Volvo Penta: TAMD 63

This Centa marine damper plate, also known as a drive plate or Centaflex dual-stage coupling is specifically developed for marine use. Its dual-stage elastic design effectively absorbs torsional vibrations and shock loads, protecting gearboxes and drivetrains while enhancing operational comfort and efficiency.
