Elaflex DN100 ERV-G 100×160.16

Elaflex DN 100 ERV-G 100×160.16

DN 100 – 4″ Length = 160mm
Temperatures: -20° + 90°, temp. up to 100°C
Lining: NBR (nitrile) seamless, abrasion resistant
Reinforcement: PA textile cord
Cover: Chloroprene CR
Flanges: Swivelling, DIN PN 10/16, carbon steel, zinc plated.

Yellow band expansion joint suitable for petroleum based products, fuel ethanol blend and DIN EN fuel up to 50% aromatic content, also town gas and natural gas, except for LP gas.
Working pressure = 16bar

Item No.: 14126609
