Stromag Electromagnetic Brake 4BZFM 25/40

Stromag Electromagnetic Spring Applied Brake 4BZFM 25/40

Hub with bore 42H7x80mm and keyway 12JS9x3.3 to DIN 6885/1 and with loose supplied Rotex coupling blue 11/11 and adaptor for hub, Cover with bore 85G7 and 6xM6 on PCD 100 and loose supplied tacho flange to be able to assemble an encoder, Electrical supply via axial flying leads – about 1.5m long, Micro switch for switching control, Heater for 240 V AC – 25 W, Flange A350.

Type: 4BZFM 25/40
Coil : 110 V DC / 163.8 W
Idle speed : 5500 rpm
Weight : 52.5 kg
Thermal class : 155 (F)
Nominal torque : 400 Nm
